TO8

12.5mm pixel pitch, 5500 nits outdoor SMD LED color screen display unit, suitable for stage rental

Pixel Pitch：

LED Specifications：

Brightness：

Maximum Power Consumption：

IP Level：

Cabinet Size：

Box Weight：

- Commodity name: TO8
- Commodity ID: TO8
12.5mm pixel pitch, 5500 nits outdoor SMD LED color screen display unit, suitable for stage rental

Outdoor strip screen PH series provides affordable LED animation display, its structure is mainly made of sturdy and durable aluminum or iron cabinet with front maintenance (front flip). Outdoor strip screen PH series adopts a user-friendly asynchronous control card, which can support common video formats such as AVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV, animations such as GIF, SWF, pictures such as BMP, JPG, GIF, WMF, ICO, text such as TXT, RTF, single-line text, static text, and multi-line text. It can automatically play advertising materials in its own internal memory or external U disk. It is an ideal display screen with a reasonable price and satisfying customers to play full-color video effects.
- 产品参数
  - Pixel Pitch：
  - LED Specifications：
  - Brightness：
  - Maximum Power Consumption：
  - IP Level：
  - Cabinet Size：
  - Box Weight：

Model	Units	P5
Pixel spacing	mm	5
LED>Configuration	-	SMD 3 in 1 3528 light
Brightness	CD/m²	2500
pixel resolution	dots	192 x 64
Display size	mm	960 x 320
Side count	-	Double-sided
Cabinet size	mm	1040 x 200 x 500
Cabinet size	feet	40.9 x 7.9 x 19.7
Cabinet Weight	kg/box	26.5
Perspective	horizontal	120° at 50% brightness
Perspective	vertical	110° at 50% brightness
Power consumption>(max/average)	w/box	900/450
Operating Voltage	-	DC9V-36V
Protection level	IP	65
operating temperature	°C	-20 to +60
Humidity	RH	5 to 95%
Supported formats	-	Video formats such as AVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV, Animation such as GIF, SWF, picture such as BMP, JPG, GIF, WMF, ICO, Text such as TXT, RTF, single-line text, static text, and multi-line text
Maintenance	-	Front and back maintenance
